TZA-4000®EM

TZA-4000?EM
400 WATTS
2 ZONE PA MIXER AMPLIFIER
Power Output
300W + 300W Max., 200W + 200W RMS at 10% THD, 180W + 180W RMS at 5% THD, 165W + 165W RMS at 2% THD
Output Regulation
? 2 dB, no load to full load at 1kHz
Input Channels
Mono 6 ? Mic 0.6mV/4.7k?, 2 ? Aux 100mV/470k?, Stereo L/R 200mV/100k?, Line L/R 1V/50k?
Frequency Response
50-15,000Hz ?3dB
Signal to Noise Ratio
60dB
Tone Controls
Bass: ?10dB at 100Hz, Treble: ?10dB at 10kHz
Outputs
Preamp 200mV/600?, Line 1V/1k?
Speaker Outputs
4?, 8?, 70V & 100V for each zone
Power Supply
AC: 220-240V 50/60Hz?DC: 24V (2?12V Car Battery)
Power Consumption
AC: 700VA?DC: 9A
Dimensions
W510 ? H172 ? D385 mm
Weight
24.2kg
6 Mic & 2 Aux Inputs.
?Stereo? Music Operation for DJ programmes.
Facilitates connection and operation of two
separate groups of speakers simultaneously on ?Mono? mode. Ideal for Places of Worship.
Line Input & Output on each zone for connecting to a Mixer and Booster Amplifier respectively. Preamplifier output for recording.
Box Speaker/Driver Unit selector switch for each zone. Bass boost defeated at Driver Unit position for safer operation of driver units. Zone On/Off facility.
Resettable circuit breaker for protection against overload and short circuit.
Instant transfer to DC power (Car Battery) if AC power fails.
