L18-SW1000

Availability:

25 in stock


16,944.92

25 in stock

L18-SW1000

Power Rating 1000W RMS
Nominal Diameter 457mm (18”)
Nominal Impedance 8Ω
Sensitivity (1W/1m ) 99 dB
Magnet Weight 5.65kg
Resonant Frequencey (Fs) 36Hz
DC Resistance (Re) 5.6Ω
Electromagnetic Q (Qes) 0.32
Mechanical Q (Qms) 14.70
Total Q (Qts) 0.31
Compliance Equivalent Volume (VAS) 249 Litr
Surface Area of Cone (Sd) 1257cm2
Reference Efficiency (ηo) 3.6%
Voice Coil 5.0”
Overhang (Xmax) 8.0 mm
Moving Mass (Mms) 169gm
BL Product (BL) 26.0TM
Coil Inductance (Le) 1.91mH
Overall Diameter 477 mm
Depth 202 mm
Baffle Hole Diameter 427 mm
Bolt Mount Diameter (PCD) 451.5 mm (8 Bolts)
Weight 19.20kg
SKU: SEB-104 Categories: , , ,

L18-SW1000

1000 WATTSSuper Power 45.72cm (18”) Extended Low Frequency Speaker

  • Super power and reliable speaker for powerful bass & subwoofer applications.
  • Robust aluminium die-cast frame with efficient heat dissipating vents. Aluminium demodulating ring fitted for further enhanced heat dissipation.
  • Double spider design for better excursion control.
  • GLASS FIBRE former voice coil for withstanding high temperatures.
  • 12.7cm (5″) inside/outside CCAW voice coil for higher SPL.
  • Cone specially treated for water splash resistance.
  • Ideal professional bass speaker for live music, sound reinforcement and all PA applications.
