L18-SW1300X

Availability:

25 in stock


  • Introducing an 18” extended low frequency speaker with matchless power and exquisite design.
  • Delivers deep, powerful bass in compact bass reflex as well as horn loaded sub-woofer design.
  • L18-SW1300X has 8Ω impedance.
  • Assembled in a strong and well vented octagonal shaped aluminium die-cast frame.
  • Aluminium demodulating ring fitted for enhanced heat dissipation.
  • Heavy duty 12.7cm (5”) copper voice coil wound inside/outside on fibreglass former for withstanding high temperatures.
  • Triple-rolled cloth surround with deep corrugations and double spider design to give better control of cone excursion.
  • Special double treated cone for water splash resistance
  • Ideal for usage in a wide variety of professional sub-woofer applications.

16,948.31

25 in stock

L18-SW1300X

Power Rating 1300W RMS/2600W Programme
Nominal Diameter 457mm (18”)
Nominal Impedance 4Ω
Sensitivity (1W/1m) 97 dB
Magnet Weight 5.65kg
Resonant Frequency (Fs) 35Hz
DC resistance (Re) 5.6Ω
Electromagnetic Q (Qes) 0.27
Mechanical Q (Qms) 12.9
Total Q (Qts) 0.26
Compliance Equivalent Volume (VAS) 209 Litr
Surface Area of Cone (Sd) 1257cm2
Reference Efficiency (ηo) 2.95%
Voice Coil 5.0″
Overhang (Xmax) 8.0mm
Moving Mass (Mms) 229gm
BL Product (BL) 32.0TM
Coil Inductance (Le) 1.73mH
Overall Diameter 475 × 455 mm
Depth 202 mm
Baffle Hole Diameter 422mm
Bolt Mount Diameter (PCD) 443 mm (8 Bolts)
Weight 18.80kg
SKU: SEB-105 Categories: , , ,

L18-SW1300X

1300 WATTS

Super Power 45.72CM (18”) Extended Low Frequency Speaker

  • Introducing an 18” extended low frequency speaker with matchless power and exquisite design.
  • Delivers deep, powerful bass in compact bass reflex as well as horn loaded sub-woofer design.
  • L18-SW1300X has 8Ω impedance.
  • Assembled in a strong and well vented octagonal shaped aluminium die-cast frame.
  • Aluminium demodulating ring fitted for enhanced heat dissipation.
  • Heavy duty 12.7cm (5”) copper voice coil wound inside/outside on fibreglass former for withstanding high temperatures.
  • Triple-rolled cloth surround with deep corrugations and double spider design to give better control of cone excursion.
  • Special double treated cone for water splash resistance
  • Ideal for usage in a wide variety of professional sub-woofer applications.
